Application Scopes
Medium: oil, water, non-crystalline acid, alkali, salt, organic solvent, etc
Temperature: -20 ~ 220℃
Pressure: ＜4 MPa
Linear velocity: ＜10 m/s
Shaft diameter: φ14 ~ φ200 mm
Viscocity: ≤300 CP
1. The multi-spring design incorporates a fork-groove drive mechanism, ensuring uniform pressure distribution across the seal face, thereby eliminating the need to consider the rotational direction. The spring retainer, spring, and thrust ring can be pre-assembled for seamless installation convenience.
2. Based on the prevailing conditions, a range of auxiliary seal rings can be chosen from, including rubber O-rings (N), PTFE V-rings (T), and PTFE wedge-shaped rings, to cater to specific sealing requirements.
3. This product adheres to the ISO3069, DIN24960, and GB6556 standards, providing extensive compatibility and wide-ranging applicability across various applications.
4. This seal type can be integrated with others or itself to form double-acting seals, offering enhanced sealing performance and reliability.
Note: In addition to offering standard-sized stationary rings in accordance with DIN24960, we can also provide other commonly used stationary ring types from international companies.
