Application Scopes
Medium: gas, oil, water, non-crystalline acid, alkali, salt, organic solvent, etc
Temperature: -50 ~ 220℃
Pressure: ＜1 MPa
Linear velocity: ＜15 m/s
Shaft diameter: φ18 ~ φ200 mm
Viscocity: ≤300 CP
1. Bellows spring design, sleeve drive mechanism, and single end face configuration. The utilization of this component is independent of the direction of rotation.
2. All other installation dimensions (d≤100 mm), excluding the installation length of the drive seat, adhere to DIN24960 standards.
During the installation of the mechanical seal, it is absolutely necessary to ensure that the quench fluid pressure remains between 0.1 and 0.2 MPa higher than the pressure of the sealed medium within the seal cavity.
